🔋 52V 28Ah 50A Triangle E-Bike Battery

✅ MSDS Certified, EU & UKCA Approved
⚡ Powered by Grade A Samsung 18650 3500mAh Cells

📊 Key Specifications

• 🔌 Nominal Voltage: 52V
• 🔋 Capacity: 28Ah
• ⚡ Energy (Wh): 1456Wh
• 🔧 Configuration: 14S8P (112 cells total)
• 🟢 Cell Type: Samsung 18650 (Grade A – 3500mAh)

⚙️ Performance

• 🚴 For Motors: 200W – 2000W
• 🔄 Max Continuous Charge Current: 4A
• ⚡ Max Constant Discharge Current: 50A (BMS)
• 🚀 Peak Discharge Current: 90A
• 🔋 Charge Cut-off Voltage: 58.8V
• 🔋 Discharge Cut-off Voltage: 42V

📐 Size & Weight

• 📏 Dimensions: 345mm x 90mm x 235mm
• ⚖️ Weight: ~10kg
• 🛠️ Designed for triangle bike frames

🔌 Charging & Output

• 🔋 Charger: 54.6V @ 3A (UK Plug included)
• ⏳ Charge Time: ~9 hours (from empty)
• ⚡ Discharge Port: XT90 (Male/Female)
• 🔄 Adapters Included: XT90 → XT60

📦 Packing List

Inside your order, you’ll receive:

• 🔋 1 × Samsung Triangle Battery
• 🔒 1 × Battery Lock
• ⚡ 1 × XT90 → XT60 Adapter
• 🔌 1 × 3A Charger with UK Plug
• 📖 1 × User Manual
• 🪢 10 × Battery Straps

🛡️ Warranty

✅ 12-Month Warranty on all battery packs.

❌ Warranty does not cover:

• 🌊 Abuse, wear & tear, or water damage
• ✂️ Any wiring/cable modifications without our consent
• 🚫 Removal of original connectors or labels
• ⚠️ Use of aftermarket parts without approval

🔧 All warranty repairs are carried out by E-Bike Power UK.
📦 Buyer is responsible for shipping both ways.

⚖️ Legality

⚠️ Please comply with your local e-bike laws & regulations.

“It is illegal to ride electric scooters on public roads, pavements, or cycle paths. They are intended
only for private land use with the landowner’s permission.”

⚡ Built tough, powerful, and efficient — perfect for high-performance DIY E-Bike builds! 🚴‍♂️🔋💨
